small linear actuator for door lock YLSL09

It can open, close, push, pull, lift and descend these devices. It can replace hydraulic and pneumatic products to save power consumption.

Housing Material: ADC12

Gear Material: Dupont 100P

Stroke and outer tube Material: Aluminum alloy

Metal housing, able to work in very harsh environments;

High strength wear-resistant gear;

Aluminum alloy telescopic tube and outer tube with anodic treatment, corrosion resistant;

Multiple speed options, from 5mm/s to 60mm/s (It is the speed at no load, and the actual working speed will gradually slow down as the load increases.);

Multiple stroke options, from 25mm to 800mm;

Built-in two limit switches, linear actuator will automatically stop when stroke lever reaches the switch;

Automatically lock after stopping, and no power supply is required;

Low power consumption and low noise;

Maintenance-free;

High-quality products and high-quality services;
